| Description |
English: Schematic diagram of the pressurised heavy water cooled version of a CANDU (CANada Deuterium-Uranium) nuclear reactor. - The pressurized heavy water (PHW) cooled version was the first type to be developed and is by far the most widely used. - A pressurised heavy water reactor is a nuclear power reactor that uses unenriched natural uranium as nuclear fuel and heavy water as moderator and as primary coolant. The heavy water is kept under pressure in order to raise its boiling point, allowing it to be heated to higher temperatures and thereby carry more heat out of the reactor core. - See below for the labels. |
||
| Date | 08/10/2007 | ||
| Source | Self-made, based on CANDU reactor schematic.png by Emoscopes | ||
| Author | Inductiveload | ||
| Other versions |
|
||
| SVG development |
|
| # | English | Français | Magyar | Deutsch | 한국어 |
|---|---|---|---|---|---|
| 1 | Nuclear fuel rod | Combustible nucléaire | Üzemanyagrudak | Kernbrennstoff | 연료봉 |
| 2 | Calandria | Cuve | Reaktortartály | Reaktorkern | 컬랜드리아 (노심) |
| 3 | Control Rods | Barres de contrôle | Szabályozórudak | Steuerstäbe | 제어봉 |
| 4 | Pressurizer | Préssurisateur | Nyomástartó | Druckausgleich | 가압기 |
| 5 | Steam generator | Générateur de vapeur | Gőzfejlesztő | Dampfgenerator | 증기발생기 |
| 6 | Light water condensate pump (secondary cooling loop) | Pompe de l'eau légère condensée (boucle de refroidissement secondaire) | Tápvízszivattyú (szekunder kör) | Pumpe für Leichtes Wasser | 경수 펌프 |
| 7 | Heavy water pump (primary cooling loop) | Pompe de l'eau lourde (boucle de refroidissement primaire) | Keringető szivattyú (primer kör) | Pumpe für Schweres Wasser | 중수 펌프(1차 냉각 장치) |
| 8 | Nuclear fuel loading machine | Machine de chargement du combustible nucléaire | Fűtőanyag-adagoló | Brennstoffladevorrichtung | 핵연료 탑재기 |
| 9 | Heavy water (moderator) | Eau lourde (modérateur) | Nehézvíz (moderátor) | Schweres Wasser als Moderator | 중수 (감속재) |
| 10 | Pressure tubes | Tubes de force | Nyomásálló csövek | Druckleitungen | 압력관 |
| 11 | Steam | Vapeur | Gőz | Wasserdampf zum Stromgenerator | 증기 |
| 12 | Water condensate | Eau condensée | Tápvíz | Kondensiertes Wasser | 복수기 |
| 13 | Reactor containment building | Enceinte du réacteur nucléaire | Vasbeton sugárzásvédelem | Sicherheitsbehälter | 격납건물 |
