File:Iron carbon phase diagram.svg
Original file (SVG file, nominally 512 × 355 pixels, file size: 397 KB)
Summary
| Description |
English: Iron–carbon phase diagram, at atmospheric pressure
This diagram is limited by pure iron on the left and by iron carbide on the right. The mains phases are:
It shows a eutectic and a eutectoid; these phases crystallise as a stacking of fine strips of pure phases (iron and cementite) in case of the eutectoid, or a pure iron containing small balls of cementite for the eutectic. Although it is heterogeneous, these phases behave like homogeneous pure bodies. Steel is between 0 and 2.06 mass percent of carbon. Cast iron is between 2.06 and 6.67%. Black lines indicate the metastable Fe/Fe3Cphase, red is the stable Fe/Carbon phase This diagram is for illustrative purposes only, and is not thermodynamically accurate.Español: Diagrama de fases hierro-carbono a presión atmosférica
Este diagrama está delimitado por hierro puro a la izquierda y carburo de hierro a la derecha. Las fases principales son:
Se muestran un eutéctico y un eutectoide; estas fases cristalizan como un apilamiento de finas tiras de fases puras (hierro y cementita) en el caso del eutectoide, o un hierro puro con pequeñas esferas de cementita en el caso del eutéctico. Aunque heterogéneo, estas fases se comportan como cuerpos puros homogéneos. El acero contiene entre 0 y 2,06 % en masa de carbono. El hierro fundido contiene entre 2,06 y 6,67 %. Las líneas negras indican la fase metaestable Fe/Fe₃C; las rojas, la fase estable Fe/Carbono. Este diagrama es solo para fines ilustrativos y no es termodinámicamente preciso. |
| Date | |
| Source |
Own work
|
| Author | AG Caesar |
